Manifold
An Arduino Nano inspired, high-temp automotive controller board built around the NXP S32K144 — designed to live in the engine bay, not just the dash.
Board size
83.4 × 38.7 mm, 4-layer
MCU
NXP S32K144 (64-LQFP, Cortex-M4F, 512 KB flash)
Grade
AEC-Q100 automotive qualified
Logic level
3.3 V
VIN range
9–40 V
Main connector
TE Connectivity AMPSEAL 776180-1, 35-position
Contact rating
8 A / pin
Sealing
IP67
Temp range
−40 to 125 °C
Reference docs
Full bill of materials and connector pinout for the board.
